Mặt Bích Tiêu Chuẩn ANSI B16.5 Welding Neck Flange Class 150
Loại:Mặt bích theo tiêu chuẩn ANSI
Mô tả sản phẩm:
Vật Liệu: Thép carbon steel...vv
Xuất Xứ: Vietnam-China,etc.
Mô tả sản phẩm: Theo tiêu chuần ANSI, ASME, ASA, B16.5
Sử dụng: Năng lượng điện, dầu khí, hóa chất, đóng tầu, thiết bị nhiệt, làm giấy, hệ thống cấp thoát nước, đường ống pccc, thực phẩm, vv
Giá: Liên hệ
Thông số kỹ thuật:
Dimensions & Masses of ANSI B16.5 WNRF Flange Class 150
GIÁ MẶT BÍCH - MẠ KẼM NHÚNG NÓNG (01/03/2014)
TÊN HÀNG | MẶT BÍCH BS | MẶT BÍCH JIS | MẶT BÍCH BS4504 | ANSI #150 | |||||||
BS5K | BS10K | Mù 10K | JIS10K | JIS20K | MÙ JIS10K | PN16 | Mù PN16 | PN25 | |||
DN15 | Ø 21 | 24,000 | 30,000 | 42,000 | 37,000 | - | 51,000 | 40,000 | 54,000 | 46,000 | 64,000 |
DN20 | Ø 27 | 29,000 | 33,000 | 46,000 | 48,000 | - | 67,000 | 46,000 | 61,000 | 54,000 | 76,000 |
DN25 | Ø 34 | 31,000 | 44,000 | 62,000 | 58,000 | - | 82,000 | 54,000 | 73,000 | 66,000 | 91,000 |
DN32 | Ø 42 | 35,000 | 52,000 | 73,000 | 63,000 | 68,000 | 88,000 | 66,000 | 90,000 | 84,000 | 93,000 |
DN40 | Ø 49 | 40,000 | 55,000 | 77,000 | 65,000 | 84,000 | 91,000 | 84,000 | 114,000 | 114,000 | 105,000 |
DN50 | Ø 60 | 49,000 | 63,000 | 88,000 | 89,000 | 100,000 | 124,000 | 96,000 | 131,000 | 156,000 | 114,000 |
DN65 | Ø 76 | 56,000 | 77,000 | 107,000 | 109,000 | 131,000 | 152,000 | 134,000 | 182,000 | 186,000 | 166,000 |
DN80 | Ø 90 | 70,000 | 93,000 | 130,000 | 131,000 | 189,000 | 184,000 | 156,000 | 212,000 | 240,000 | 223,000 |
DN100 | Ø 114 | 81,000 | 103,000 | 144,000 | 160,000 | 223,000 | 224,000 | 198,000 | 269,000 | 276,000 | 338,000 |
DN125 | Ø 141 | 97,000 | 131,000 | 184,000 | 171,000 | 366,000 | 240,000 | 276,000 | 376,000 | 360,000 | 389,000 |
DN150 | Ø 168 | 126,000 | 185,000 | 259,000 | 257,000 | 486,000 | 360,000 | 348,000 | 473,000 | 456,000 | 457,000 |
DN200 | Ø 219 | 189,000 | 234,000 | 328,000 | 360,000 | 606,000 | 504,000 | 504,000 | 685,000 | 660,000 | 709,000 |
DN250 | Ø 273 | 263,000 | 360,000 | 504,000 | 514,000 | - | 720,000 | 780,000 | 1,060,000 | 936,000 | 903,000 |
DN300 | Ø 325 | 343,000 | 480,000 | 672,000 | 566,000 | - | 792,000 | 972,000 | 1,321,000 | 1,176,000 | 1,491,000 |
DN350 | Ø 355 | 555,000 | 566,000 | 793,000 | 807,000 | - | 1,131,000 | 1,500,000 | 2,039,000 | 2,100,000 | 2,411,000 |
DN400 | Ø 406 | 628,000 | 841,000 | 1,178,000 | 1,234,000 | - | 1,727,000 | 1,860,000 | 2,528,000 | 2,460,000 | 3,129,000 |
DN450 | Ø 457 | 729,000 | 998,000 | 1,397,000 | 1,626,000 | - | 2,277,000 | 2,700,000 | 3,670,000 | 3,280,000 | - |
DN500 | Ø 508 | 785,000 | 1,110,000 | 1,554,000 | 1,963,000 | - | 2,748,000 | 3,360,000 | 4,567,000 | 4,440,000 | - |
DN550 | Ø 556 | 1,009,000 | 1,402,000 | 1,963,000 | 2,860,000 | - | 4,004,000 | 4,380,000 | 5,953,000 | 5,322,000 | - |
DN600 | Ø 610 | 1,851,000 | 2,636,000 | 3,690,000 | 3,589,000 | - | 5,024,000 | 5,220,000 | 7,096,000 | 6,600,000 | - |
GIÁ MẶT BÍCH – XI KẼM (01/03/2014)
TÊN HÀNG | MẶT BÍCH BS | MẶT BÍCH JIS | MẶT BÍCH BS4504 | ANSI #150 | |||||||
BS5K | BS10K | Mù 10K | JIS10K | JIS20K | MÙ JIS10K | PN16 | Mù PN16 | PN25 | |||
DN15 | Ø 21 | 22,000 | 27,000 | 38,000 | 34,000 | - | 46,000 | 36,000 | 49,000 | 42,000 | 58,000 |
DN20 | Ø 27 | 26,000 | 30,000 | 42,000 | 44,000 | - | 61,000 | 42,000 | 55,000 | 49,000 | 69,000 |
DN25 | Ø 34 | 28,000 | 40,000 | 56,000 | 53,000 | - | 75,000 | 49,000 | 66,000 | 60,000 | 83,000 |
DN32 | Ø 42 | 32,000 | 47,000 | 66,000 | 57,000 | 62,000 | 80,000 | 60,000 | 82,000 | 76,000 | 85,000 |
DN40 | Ø 49 | 36,000 | 50,000 | 70,000 | 59,000 | 76,000 | 83,000 | 76,000 | 104,000 | 104,000 | 95,000 |
DN50 | Ø 60 | 45,000 | 57,000 | 80,000 | 81,000 | 91,000 | 113,000 | 87,000 | 119,000 | 142,000 | 104,000 |
DN65 | Ø 76 | 51,000 | 70,000 | 97,000 | 99,000 | 119,000 | 138,000 | 122,000 | 165,000 | 169,000 | 151,000 |
DN80 | Ø 90 | 64,000 | 85,000 | 118,000 | 119,000 | 172,000 | 167,000 | 142,000 | 193,000 | 218,000 | 203,000 |
DN100 | Ø 114 | 74,000 | 94,000 | 131,000 | 145,000 | 203,000 | 204,000 | 180,000 | 245,000 | 251,000 | 307,000 |
DN125 | Ø 141 | 88,000 | 119,000 | 167,000 | 155,000 | 333,000 | 218,000 | 251,000 | 342,000 | 327,000 | 354,000 |
DN150 | Ø 168 | 115,000 | 168,000 | 235,000 | 234,000 | 442,000 | 327,000 | 316,000 | 430,000 | 415,000 | 415,000 |
DN200 | Ø 219 | 172,000 | 213,000 | 298,000 | 327,000 | 551,000 | 458,000 | 458,000 | 623,000 | 600,000 | 645,000 |
DN250 | Ø 273 | 239,000 | 327,000 | 458,000 | 467,000 | - | 655,000 | 709,000 | 964,000 | 851,000 | 821,000 |
DN300 | Ø 325 | 312,000 | 436,000 | 611,000 | 515,000 | - | 720,000 | 884,000 | 1,201,000 | 1,069,000 | 1,355,000 |
DN350 | Ø 355 | 505,000 | 515,000 | 721,000 | 734,000 | - | 1,028,000 | 1,364,000 | 1,854,000 | 1,909,000 | 2,192,000 |
DN400 | Ø 406 | 571,000 | 765,000 | 1,071,000 | 1,122,000 | - | 1,570,000 | 1,691,000 | 2,298,000 | 2,236,000 | 2,845,000 |
DN450 | Ø 457 | 663,000 | 907,000 | 1,270,000 | 1,478,000 | - | 2,070,000 | 2,455,000 | 3,336,000 | 2,982,000 | - |
DN500 | Ø 508 | 714,000 | 1,009,000 | 1,413,000 | 1,785,000 | - | 2,498,000 | 3,055,000 | 4,152,000 | 4,036,000 | - |
DN550 | Ø 556 | 917,000 | 1,275,000 | 1,785,000 | 2,600,000 | - | 3,640,000 | 3,982,000 | 5,412,000 | 4,838,000 | - |
DN600 | Ø 610 | 1,683,000 | 2,396,000 | 3,355,000 | 3,263,000 | - | 4,567,000 | 4,745,000 | 6,451,000 | 6,000,000 | - |
GIÁ MẶT BÍCH ĐEN CÁC LOẠI (01/06/12)
TÊN HÀNG | MẶT BÍCH BS | MẶT BÍCH JIS | MẶT BÍCH BS4504 | ANSI #150 | |||||||
BS5K | BS10K | Mù 10K | JIS10K | JIS20K | MÙ JIS10K | PN16 | Mù PN16 | PN25 | |||
DN15 | Ø 21 | 20,000 | 25,000 | 35,000 | 30,000 | - | 43,000 | 33,000 | 45,000 | 38,000 | 53,400 |
DN20 | Ø 27 | 24,000 | 27,000 | 38,000 | 39,000 | - | 56,000 | 38,000 | 51,000 | 45,000 | 63,100 |
DN25 | Ø 34 | 25,000 | 37,000 | 51,000 | 48,000 | - | 68,000 | 45,000 | 61,000 | 55,000 | 75,700 |
DN32 | Ø 42 | 29,000 | 43,000 | 61,000 | 51,000 | 56,000 | 73,000 | 55,000 | 75,000 | 70,000 | 77,700 |
DN40 | Ø 49 | 33,000 | 45,000 | 63,000 | 53,000 | 70,000 | 76,000 | 70,000 | 95,000 | 95,000 | 87,400 |
DN50 | Ø 60 | 40,000 | 52,000 | 73,000 | 72,000 | 83,000 | 103,000 | 80,000 | 109,000 | 130,000 | 95,100 |
DN65 | Ø 76 | 47,000 | 64,000 | 90,000 | 90,000 | 112,000 | 129,000 | 110,000 | 152,000 | 155,000 | 138,100 |
DN80 | Ø 90 | 59,000 | 78,000 | 109,000 | 110,000 | 160,000 | 156,000 | 130,000 | 177,000 | 200,000 | 185,700 |
DN100 | Ø 114 | 68,000 | 87,000 | 121,000 | 133,000 | 189,000 | 190,000 | 160,000 | 224,000 | 230,000 | 281,900 |
DN125 | Ø 141 | 82,000 | 111,000 | 155,000 | 143,000 | 311,000 | 204,000 | 220,000 | 313,000 | 300,000 | 323,800 |
DN150 | Ø 168 | 106,000 | 156,000 | 218,000 | 214,000 | 413,000 | 306,000 | 280,000 | 394,000 | 380,000 | 381,000 |
DN200 | Ø 219 | 159,000 | 197,000 | 276,000 | 300,000 | 515,000 | 428,000 | 440,000 | 571,000 | 550,000 | 590,500 |
DN250 | Ø 273 | 221,000 | 303,000 | 424,000 | 429,000 | - | 612,000 | 650,000 | 883,000 | 780,000 | 752,400 |
DN300 | Ø 325 | 288,000 | 404,000 | 565,000 | 471,000 | - | 673,000 | 790,000 | 1,101,000 | 980,000 | 1,242,900 |
DN350 | Ø 355 | 476,000 | 486,000 | 680,000 | 686,000 | - | 979,000 | 1,290,000 | 1,699,000 | 1,750,000 | 2,009,300 |
DN400 | Ø 406 | 538,000 | 721,000 | 1,010,000 | 1,048,000 | - | 1,495,000 | 1,590,000 | 2,107,000 | 2,050,000 | 2,607,500 |
DN450 | Ø 457 | 625,000 | 856,000 | 1,198,000 | 1,381,000 | - | 1,971,000 | 2,400,000 | 3,058,000 | 2,733,600 | - |
DN500 | Ø 508 | 673,000 | 952,000 | 1,333,000 | 1,667,000 | - | 2,379,000 | 2,900,000 | 3,806,000 | 3,700,000 | - |
DN550 | Ø 556 | 865,000 | 1,202,000 | 1,683,000 | 2,429,000 | - | 3,466,000 | 3,800,000 | 4,961,000 | 4,434,600 | - |
DN600 | Ø 610 | 1,587,000 | 2,260,000 | 3,163,000 | 3,048,000 | - | 4,350,000 | 4,500,000 | 5,913,000 | 5,500,000 | - |
